News
Direct connector in 1.00mm pitch
The product name "Card Edge" already describes the function and contact area of the component.
This way, another board is contacted without detours at the edge of the board: An additional connector is not required, this creates space on the circuit board and reduces the assembly effort.
With a pitch of 1.00mm, the design of the 1282 series is ideally suited for space-saving solutions in the…
More...
High-speed board-to-board connector for data rates of up to 28 GB/s
They are used wherever compact stacking of printed circuit boards in limited space is required. We are talking about B-t-B (board-to-board) connectors, which, thanks to their low overall height, guarantee a minimum PCB clearance. As the data rate increases almost proportionally to the shrinking housing size, W + P's new B-t-B connectors also offer an optimal solution:
The SMT series are designed for moder…
More...
Wire-to-board IDC connector in two pitches
With the W-t-B IDC series 601 and 602, W + P presents an option for processing larger cable cross-sections. This makes it possible to connect cables quickly. The connectors themselves can also be easily installed in the field using hand tools.
The insulation displacement area of the 601 series is designed for a wire cross section of AWG 28 - 22, the grid dimension is 2.54mm. With the 602 series, the con…
More...
